| Tubular condenser | Tubular condenser
Spiral plate heat exchanger is an efficient heat exchange device suitable for convective heat transfer between steam, steam liquid, and liquid liquid. It is suitable for industries such as chemistry, petroleum, solvents, pharmaceuticals, food, light industry, textiles, metallurgy, steel rolling, coking, etc. According to its structural form, it can be divided into non detachable (Type I) and detachable spiral plate (Type II, III) spiral plate heat exchangers.
Parameter
| The tube and tube condensers produced by our factory are divided into three types based on material: carbon steel tube and tube condensers, stainless steel tube and tube condensers, and carbon steel and stainless steel mixed tube and tube condensers. They are divided into fixed tube sheet type, floating head type, and U-shaped tube heat exchangers according to form, and are divided into single tube pass, double tube pass, and multiple tube passes according to structure. The heat transfer area is 0.5-500 square meters, which can be customized according to user needs.
|
 |
Nominal
diameter |
Tube
side |
Tube
数量 |
Nominal/calculated heat exchange area
|
Tube side channel cross-sectional area Tube side channel
Flow rate at 0.5m/sec m/hr
|
Nominal
pressure |
| 管子长度（m） |
φ25×2.5 |
| 1500 |
2000 |
3000 |
4000 |
6000 |
φ25×2 |
| 159 |
1 |
14 |
1.51.62 |
22.17 |
33.27 |
|
|
0.0044/0.0049 |
7.92/8.82 |
0.25 |
| 219 |
1 |
26 |
3/3.00 |
4/4.02 |
6/6.06 |
8/8.1 |
|
0.0082/0.0090 |
14.76/16.20 |
0.6 |
| |
2 |
26 |
3/3.00 |
4/4.02 |
6/6.06 |
8/8.81 |
|
0.0041/0.0045 |
7.38/8.01 |
1.0 |
| 273 |
1 |
44 |
5/5.08 |
7/5.18 |
10/10.26 |
14/13.72 |
21/20.63 |
0.0138/0.0152 |
24.84/27.36 |
1.6 |
| |
2 |
40 |
5/4.62 |
6/6.19 |
9/9.33 |
12/12.47 |
19/18.76 |
0.0063/0.0069 |
11.24/12.42 |
2.5 |
| 325 |
1 |
60 |
7/6.93 |
9/9.28 |
14/14.00 |
19/18.71 |
28/28.13 |
0.0188/0.0208 |
33.84/37.44 |
0.6 |
| |
2 |
56 |
6/6.47 |
9/8.66 |
13/13.05 |
17/17.46 |
36/26.26 |
0.0088/0.0097 |
15.84/17.46 |
1.0 |
| 400 |
1 |
119 |
14/13.47 |
18/18.41 |
28/27.76 |
37/37.10 |
55/55.8 |
0.0374/0.0412 |
67.32/74.16 |
1.6 |
| |
2 |
110 |
13/12.70 |
17/17.02 |
26/25.66 |
34/34.20 |
50/51.58 |
0.0173/0.0190 |
31.14/34.20 |
2.5 |
| 500 |
1 |
185 |
|
|
45/4.15 |
55/57.68 |
85/86.74 |
0.0581/0.0641 |
104.58/115.38 |
|
| |
2 |
180 |
|
|
40/41.99 |
55/57.68 |
85/86.74 |
0.0283/0.0312 |
50.94/56.16 |
|
| 600 |
1 |
269 |
|
|
60/62.7 |
85/83.88 |
125/126.13 |
0.0845/0.0932 |
152.10/167.76 |
|
| |
2 |
266 |
|
|
60/32.05 |
80/82.94 |
125/14.72 |
0.0418/0.0461 |
75.24/83.98 |
|
| 700 |
1 |
379 |
|
|
90/88.41 |
120/118.17 |
175/177.71 |
0.0091/0.1313 |
214.38/236.34 |
|
| |
2 |
358 |
|
|
85/83.51 |
110/111.62 |
165/167.85 |
0.0562/0.0620 |
101.16/111.60 |
|
| 800 |
1 |
511 |
|
|
120/119.20 |
160/159.16 |
240/239.60 |
0.1605/0.1770 |
288.90/318.60 |
|
| |
2 |
488 |
|
|
115/113.83 |
150/152.16 |
230/228.81 |
0.0767/0.0845 |
138.06/152.10 |
|
| 900 |
1 |
649 |
|
|
150/151.39 |
200/202.36 |
305/304.3 |
0.2039/0.2248 |
367.02/404.46 |
|
| |
2 |
630 |
|
|
145/146.96 |
195/196.44 |
295/295.40 |
0.0990/0.1091 |
178.20/196.38 |
|
| 1000 |
1 |
805 |
|
|
185/187.78 |
250/251.00 |
375/377.45 |
0.2529/0.2788 |
455.22/501.74 |
|
| |
2 |
792 |
|
|
185/184.75 |
245/246.95 |
370/371.36 |
0.1244/0.1374 |
223.92/246.96 |
|
The tubular condenser is the main product of Wuxi Nanquan Chemical Complete Equipment Co., Ltd. With years of rich experience in producing tubular condensers, its reputation and performance have won the trust of many enterprises. Welcome to purchase tubular condensers and other products, and inquire about the price and service phone number of tubular condensers: 0510-85953983
| | |   |
|
|
